Higher Stability Car Parking Gate Auto Reversing Toll Barrier Gate Die Casting

Brand Name : WEJOIN

Model Number : WJDZ102

Certification : CE,ISO,

Place of Origin : China

MOQ : 1 unit

Price : negotiation

Payment Terms : T/T, Western Union

Supply Ability : 5000 Units / Month

Delivery Time : 3-7 working days

Packaging Details : Carton,wooden box

Trade Terms : EXW,FOB,CIF

Speed : 1S; 1.8S; 3S; 6S

Color : Orange

Motor Material : Die-casting Aluminum alloy

Housing Material : Steel

Max Boom Length : 8 metes

COM Interface : RS485

Contact Now

Higher stability Automatic Car Parking Gate Barrier System Toll Barrier Gate

Toll Barrier Straight boom installation

Step 1. Fix the boom holder pressboard on the boom with 2pcs of M12*70mm hexagon screw.

Step 2. Press the board by hand, then lift up the boom vertically and install it on the boom holder.

Step 3. Install the flat washer, spring washer, and M12 nut on the screw in turn, and fix the screw with a wrench.

Barrier Gate Technical Data

1. Working temperature (motor): -35℃~ + 70℃

2. Power supply: 220V±10% 50/60 Hz; 110V±10% 50/60 Hz

3. Net weight: 60 Kg

4. Rated power: 120W

5. Relative Humidity: 30%~80%, No condensation

6. Distance of remote control: L≥30M

Parking Barrier Spring selection

Balance spring dimension 50*440mm

The Innerspring has a rubber cover and PVC tube.

The innerspring dimension is 3.0*26mm

It is innerspring if the boom length is 5.5m-6m.

There are three small compression springs inside with rubber cover to each other to make the boom is more reliable and safe as well as to reduce the fatigue of the spring. The PVC is to fix the innerspring, then install in the large spring of 6.4mm

number Boom length Spring parameter(mm) Hole position(1or 2)
1 2.5 <L<3.5 D=4.5 Hole2
2 3.5≤L≤4.0 D=5.5 Hole1
3 4.0<L<5.5 D=6.5 Hole2
4 5.5≤L≤6.0 D=6.5 Hole1

The data is according to the boom produced in our company.
